PANORAMA

SYSTEM

The Perfect Solution for Glass Support.

THE SYSTEM

With our expertise in design and manufacturing, we bring you an innovative system that allows for the creation of customized railings to meet your project’s specific requirements. At RAMI, product development is a continuous endeavor, ensuring that our offerings reflect the latest advancements in the railing industry.

Discover our diverse range of Cap Rails, Hand Rails, and Hand Rail Brackets, providing a comprehensive solution for all your railing needs.

PARTS

Previous
Next

GALLERY

RAMI PANORAMA STANDOFF SYSTEM

  • Round Designs Offered for
    Exterior and Interior Applications
  • Two Architectural Finishes Available,
  • Compact Design for Minimal Obstruction
  • Designed for Guard Rail, Stairway or Ramp Areas
  • Meets or Exceeds A.D.A. Requirements
  • Custom Engineering and Fabrication Available
  • Spacing: Maximum horizontal spacing between fittings depends
    on its use and mounting conditions. The minimum height spacing
    is 6″ (102 mm) center-to-center.



GLASS SPECIFICATIONS:

  • For Use With 1/2″ and 3/4″ (12 and 19 mm)
    Monolithic Tempered Glass or 9/16″ and
    11/16″ (13.52 and 21.52 mm) Laminated
    Tempered Glass Using DuPont® SentryGlas®
    Interlayers
  • One 3/4″ (19 mm) Diameter Hole Per Fitting.
